The A'PEXi N1 Evolution Extreme (N1-X) builds on the straight-through layout of the N1 muffler. An internal hybrid silencer balances flow with sound resonance, and the titanium tip is rolled and riveted onto a double-pipe structure that acts as a diffuser to reduce temperature, with a heat-gradation finish.
Features
- TIG-welded SUS304 stainless steel construction
- Matched and manufactured for select chassis
- Patented megaphone piping structure for torque and throttle response; the design creates a swirling exhaust-gas flow
Specifications
- Part Number: 164-T004J
- Exhaust Type: N1 Evolution Extreme Muffler (N1-X)
- Piping Diameter: 50mm. - 50mm. x 2 - 50mm. x 4
- Tip Diameter: 75mm. x 4
- Exhaust Tip Style: Titanium Round- Dual wall rolled, Angle cut (Riveted)
- Pieces: 2
- Piping Material: SUS304 Stainless Steel
- Muffler Material: SUS304 Stainless Steel
- Muffler Tip Material: Titanium
- System Weight: 31.75 lbs.
- Bolt-On Installation: Yes
Fitment
- Year: 2018
- Make: Toyota
- Model: C-HR
- Body Style: Subcompact Crossover SUV
- Engine: 3ZR-FAE
- Chassis: ZYX10
Notes
- Package Dimension: 60" x 12" x 20", Package Weight: 45 lbs.
| Brand | A'pexi |
|---|---|
| Type | Cat-Back Exhaust |
| SKU | 164-T004J |
| Weight | 65.0 lb |
| Make | ["Toyota"] |
| Model | ["C-HR"] |
| Material | ["gid://shopify/Metaobject/91049197865","gid://shopify/Metaobject/90679279913"] |
| Manufacturer Type | ["gid://shopify/Metaobject/90137755945"] |
