The A'PEXi N1 Evolution Extreme (N1-X) builds on the straight-through layout of the N1 muffler. An internal hybrid silencer balances flow with sound resonance, and the titanium tip is rolled and riveted onto a double-pipe structure that acts as a diffuser to reduce temperature, with a heat-gradation finish.
Features
- TIG-welded SUS304 stainless steel construction
- Matched and manufactured for select chassis
- Patented megaphone piping structure for torque and throttle response; the design creates a swirling exhaust-gas flow
Specifications
- Part Number: Stainless Steel: 164AKT17; Titanium: 164-KT17
- Exhaust Type: N1 Evolution Extreme Muffler (N1-X)
- Piping Diameter: 65mm. - 50mm. x 4
- Tip Diameter: 75mm. x 4
- Exhaust Tip Style: Oval-Dual wall rolled, Angle cut
- Pieces: 2
- Piping Material: SUS304 Stainless Steel
- Muffler Material: SUS304 Stainless Steel
- Muffler Tip Material: SUS304 Stainless Steel; Titanium
- System Weight: 33.85 lbs. (Includes Rear Section of Exhaust System, gaskets and hardware pack) (Stock- 36.85 lbs.) 3 lbs. lighter than stock.
- Bolt-On Installation: Yes
Fitment
- Year: 2018-2021
- Make: Lexus
- Model: NX300 (Turbo)
- Body Style: 5-Door SUV
- Engine: 8AR-FTS
- Chassis: AGZ10, AGZ15
Notes
- NOTE: OEM Factory exhaust tip covers must be removed for installation.
- Sound Level: 89.7 dB @ 4,500 RPM. Modular design: Midpipe and Rear Section can be interchanged with factory exhaust components.
| Brand | A'pexi |
|---|---|
| Type | Axle-Back Exhaust |
| SKU | 164-KT17 |
| Weight | 30.0 lb |
| Make | ["Lexus"] |
| Model | ["NX"] |
| Material | ["gid://shopify/Metaobject/91049197865","gid://shopify/Metaobject/90679279913"] |
| Manufacturer Type | ["gid://shopify/Metaobject/90137755945"] |
Shipping: Some items may qualify for free shipping with Local Pickup in store. All orders have a 2–3 business day processing time. Some orders may have extended shipping times based on current stock status — we'll confirm the lead time at order placement.
Returns: Accepted within 30 days of delivery for unused product in original packaging. Returns are subject to a 25% Restocking Fee. Special-order and custom-built items are final sale.
Warranty: All products carry the manufacturer's full warranty. Coverage is honored through PMD as your authorized dealer.
No reviews yet — be the first to share your experience.
